Network OTAP Procedure
Preparing The Scratchpad
The OTAP scratchpad is a container file that can have one or multiple firmware and application images. Most common use cases are a single stack firmware image, a single application image and both the stack firmware and an application image. If updating to a new stack firmware version the safest OTAP scratchpad image type contains both the new stack firmware and the application compiled with a matching SDK version.
The OTAP image with just the stack firmware is provided in the Wirepas Mesh firmware release as a file wirepas-firmware-xxxx-vy.z.otap. This can be used as is for updating just the stack firmware. If an application is already present in the device, it is not affected.
To generate an OTAP scratchpad containing the stack firmware and application or just the application the Python script file genscratchpad.py from the Wirepas Mesh SDK is used. WP-RM-108 – OTAP reference Manual [1] Appendix A gives a description on how to use the Python script.
Each of the image contained in the scratchpad contains a hardware ID and a memory area ID that are also set by the genscratchpad.py. Those need to match to the software running in the device for the images to be taken into use during device boot, but the device will still store the scratchpad and upload it to its neighbors even if itself cannot use it. In this way the hardware IDs and memory area IDs can be used to update a heterogenous network having devices with different hardware and application profiles.
The OTAP scratchpads also contain a sequence number that is used to decide which one of the scratchpad is the newer one that should be written over the old one. The sequence number is a one byte cyclical value that has two special values. 0 indicates that the OTAP is turned off in this device, i.e. the device will not accept new scratchpads from the neighboring nodes. It can still be written over through Wirepas Mesh Dual-MCU API. Value 255 means that the scratchpad will be overwritten by any other scratchpad that is available in the network.
Since the scratchpad sequence is cyclical it means that it wraps around by doing the comparison in reverse if the difference of sequence numbers is more than 128. In practice this means that for example sequence number 1 is higher that sequence number 200. Please refer to WP-RM-100 – Wirepas Mesh Dual-MCU API [3] chapter 2.7 as to how the comparison is done in this case.
While the otap scratchpad file has its own scratchpad sequence that can be used as a default value by the tools, it is still separately defined during the scratchpad upload.
Checking the OTAP Status In The Network
It is a good idea to check the OTAP status in the network so that the scratchpad sequence numbers that are stored in the devices are known before OTAP. This is done through the Wirepas Mesh Dual-MCU API ‘s MSAP-REMOTE_STATUS.request. The Wirepas tools and APIs generally support this. Besides the scratchpad sequence number, the remote status responses contain a lot more information about the current running stack firmware. See [3] chapter 2.3.16 for further details.
Check Battery Levels (Optional)
The OTAP process consumes significantly more energy than regular network operation. In case devices in the network are battery powered, it is a good idea to check battery voltage levels beforehand.
The battery levels are contained in the node diagnostics coming from the devices. See [4] chapter 2.3 for further details.
Uploading The Scratchpad To The Sink
First step in the actual OTAP process is uploading the scratchpad to a device in the network. In theory, this can be any device, but it is usually done through the sinks that are used to control the OTAP procedure for the whole network.
The scratchpad is uploaded to a sink by using the MSAP-SCRATCHPAD services in the Wirepas Mesh Dual-MCU API. See [3] chapter 2.3.15 for further details on the primitives used.
In simplified form this is done in steps:
Stop the stack in the sink with MSAP-STACK_STOP. See [3] chapter 2.3.3
Upload the scratchpad using the MSAP-SCRATCHPAD services mentioned above
Start the stack in the sink with MSAP-STACK_START. See [3] chapter 2.3.3
This should be done to all the sinks in the network to make sure that the whole network is updated.
After the sinks have restarted, they will start uploading the new scratchpad to their immediate neighbors that in turn will upload it to their neighbors. In this way, all the devices in the network will get the latest scratchpad.
Tracking The Scratchpad Deployment To The Network
To track the deployment of the new scratchpad the devices will send OTAP remote status messages to sinks. These are the same primitives that the OTAP remote status query uses. See [3] chapter 2.3.14.3 for details.
Due to constant reformation of the network while scratchpad is being deployed, some of the status messages might be lost on their way to sink. To make sure that all the nodes have the correct scratchpad, the remote status request from chapter 3.2 can be issued again.
Decision For Taking The Scratchpad Into Use
After all the devices in the network have received the new scratchpad, the new scratchpad can be taken into use. To do this, an update request command is send to all the nodes using MSAP-REMOTE_UPDATE.request. The request contains the sequence number for the scratchpad to be taken into use and a delay in seconds how long the device will wait until it reboots. Delay of 0 seconds will cancel the ongoing update request. See [3] chapter 2.3.14.4 for details.
Please note that in the case that the sinks are not supposed to be updated with the scratchpad that has been deployed to the network, a scratchpad with the scratchpad sequence number zero needs to be saved to the sinks before the remote update requests are sent. Otherwise the sinks might receive remote update requests from each other and update to the firmware that should only be running in the nodes.
Follow-up To Know When Scratchpad Is Taken Into Use
After the scratchpad is taken into use in the devices, the sinks should receive boot info diagnostics messages (See [4] chapter 2.4) from the nodes.
Again, due to boots in the network, some of the boot messages are potentially lost, so it is a good idea to query the remote scratchpad status as was done in chapters 3.2 and 3.5.
If the scratchpad contained a matching stack firmware, the “processed scratchpad sequence number” in the scratchpad status response should contain the new scratchpad sequence number.
In the case the scratchpad contained only an application or multiple applications, the “processed scratchpad sequence number” will not change. The application update then needs to be checked through application functionality.
Take The Scratchpad In Use In The Sinks
If the sinks are also going to be using the same scratchpad then also a local update request is send to the sink using MSAP-SCRATCPAD_UPDATE.request (see [3] chapter 2.13.15.7) and then stopping and starting the stack through MSAP-STACK_STOP and MSAP-STACK_START (see [3] chapter 2.3.3) to reboot the sink and allow bootloader to take the new image into use.
[]{#_Toc5632489 .anchor}
Tools for OTAP
Wirepas Mesh API Host Library (Python)
Wirepas Mesh API Host Library (Python), later shortened to Python API library, has all the necessary functions to update a network with OTAP. It is possible to easily write a script to do an OTAP with the functions found in the MeshApiDevice class.
Using The MeshApiDevice From meshapi.py
The MeshApiDevice class has all the required functions to do an OTAP. Following the steps from chapter 3 of this document a script can be created to do this from one or multiple sinks.
Check the battery levels from node diagnostics by starting the diagnostics listener using MeshApiDevice.start_node_diag_rx and then receiving the diagnostics with MeshApiDevice.get_node_diag_rx which returns a dictionary containing the value “voltage” for each diagnostics message. See [4] chapter 2.3 on how to convert the values to voltages.
Get the scratchpad information from the network by sending the remote status query with MeshApiDevice.otap_remote_status then starting the listening with MeshApiDevice.wait_remote_status_indication_rx and receiving the status messages with MeshApiDevice.get_remote_status_indication_rx. If the network is large then multiple status request might be needed to get all the answers.
Load the OTAP image from a file by creating an instance of otapimage.OTAPImage and then loading the file to the instance with OTAPImage.load_file function.
Upload the OTAP image to the sink by first stopping the stack with MeshApiDevice.stack_stop and then uploading the image with MeshApiDevice.load_otap_image. The OTAP sequence number can then be redefined with the otap_sequence function parameter. Then start the stack.
Use methods from step 2 to check the remote status from the nodes. The remote status indications come automatically when the nodes receive scratchpad but resending the status query is probably required.
When all the nodes have received the new image then send the update query using MeshApiDevice.otap_remote_update_request. The responses for this can be also read using the MeshApiDevice.get_remote_status_indication_rx. Note that a scratchpad image with a sequence number zero needs to be loaded to the sinks before sending the remote update requests in case that the sinks are not supposed to take the image in use.
The boot diagnostics messages from the devices can be received using the MeshApiDevice.start_boot_rx and MeshApiDevice.get_boot_rx functions.
Use the same method as in step 2 to check the status of the network after the update.
Update the sink by stopping the sink with MeshApiDevice.stack_stop, setting the image bootable in the sink by MeshApiDevice.set_otap_image_bootable, the stopping the stack again to reboot the device and then starting the stack with MeshApiDevice.stack_start.
Using The load_otap_image.py, find_all_nodes.py and get_network_otap_status.py scripts for doing the OTAP
Listed scripts are delivered along with Python API 2.1.8, following steps describes the process
Check the current OTAP status of the NW to see current processed scratchpad:
python get_network_otap_status.py -c (-f config.ini)
- -c parameter is used to compress the list of nodes into more readable format. Very usable in NWs, having high amount of nodes
Load new scratchpad to NW. Sequence id is current sequence id + 1
python load_otap_image.py --otapfile <path to file>*.otap --sequence (id+1) --noupdate --startstack (--configfile config.ini)
- --noupdate used so that sink would not take nodes’ FW into use
Make sure that all nodes come alive after scratchpad transfer, in case there are more than 1 sink, use '-sa' or '--sinkamount' parameter and use the expected value for sinkamount
- python find_all_nodes.py -c (-f config.ini) (-sa <desired amount>)
Check that all nodes have stored the new scratchpad
- python get_network_otap_status.py -c (-f config.ini)
Take new scrathpad into use for all nodes (remember to check sequence id used with parameter -u):
python get_network_otap_status.py -c -u (desired id) -d 120 (-f config.ini)
- -d parameter stands for delay, which is the desired time that node would wait before taking the action
Stop the command execution after all nodes has responded, although they are still using the old version
Check that all nodes have taken the new version into use.
- python get_network_otap_status.py -c (-f config.ini)
Load new fw into sink with sequence number 0, this works for one or more sinks connected into GW
- python load_otap_image.py --otapfile <path to file>*.otap --sequence 0 --startstack (--configfile config.ini) (-sa)
Verify that all the whole NW is up and running, not needed if verified already before sink update
- python get_network_otap_status.py -c (-f config.ini)
Using The otap_nw.py and otap_nw.ini scripts for doing the OTAP
This is the most automatized way for doing the OTAP, introduced along with Python API 2.1.8 ,all you need to do is:
Edit the content of otap_nw.ini to correspond your NW setup
Run script
- Python otap_nw.py
Following things are defined in otap_nw.ini: OTAP files for nodes and sinks, number of nodes expected to be in the network, different timeout values and repeat count for getting OTAP status from the network.
If node amount in network is not known, or if it can vary during the OTAP, then nbr_of_nodes can be set to value 0. In this case, the script will wait in each phase until defined timeout is reached, before continuing to next phase, so the script execution might take a long time. When node amount is known (nbr_of_nodes is set to non-zero value), the script will continue to next phase once defined criteria (e.g. all nodes has stored the new scratchpad) is met.
Some command line arguments can be used when executing the otap_nw.py script:
--configfile or -f: load custom configuration .ini file
--interval or -i: change default otap status polling interval
--repeats or -r: define how many times update request broadcast is repeated
--ignorelist: otap status of listed nodes is ignored
--nosink: sink is not updated
Example commands:
python otap_nw.py -f custom_config.ini –nosink
if script cannot connect to sink, then custom configuration may be needed
with this -f argument, custom configuration is given. It e.g. defines serial connection towards sink
with argument –nosink, sink update is skipped
python -m wirepas.tools.otap_nw.ini
- otap is done with default argument values and parameter values defined in otap_nw.ini file
NOTE: otap_nw.ini needs to be located in the same directory from which the script is started
otap_nw.ini file itself has more information about its parameters.
There is also some information about command line arguments in the script help
- python otap_nw.py -h
Wirepas Terminal
It is also possible to do an OTAP with Wirepas Terminal in Windows, but this is mostly feasible for small networks since it is hard to keep track on what is the status of the network and you have to connect all the sinks to separate Wirepas Terminals.
Connect to each sink with Wirepas Terminal by serial connection or using a serial-to-TCP/IP bridge. Check that the stack is running from the left side bottom of the window. Choose Tools-> Start stack if it isn’t. Then follow these steps:
To get the current scratchpad sequences in the network open the OTAP window from Tools -> OTAP operations.. and then press “Get status” from the Remote operations. Now the OTAP status messages should appear in the Terminal main window.
To load the OTAP image in the sink stop the stack from Tools -> Stop stack then select Tools -> OTAP operations.. Select the file with Browse.. button and then check the Sequence number in the File column of the table below. Edit the sequence number if needed and press “Save to node”. Now the OTAP image is being uploaded to the sink. Check from the main window that it succeeds.
To deploy the scratchpad into the network, simply start the stack from Tools -> Start stack. You can now follow the OTAP status messages from the main window. Wait 5-10 minutes on 10-20 node networks and up to 30 minutes on 100 node networks.
Open the Tools -> OTAP operations window again. From Remote operations, check that the Sequence number matches to the saved sequence number and edit if needed. Then check Reboot delay. 300 seconds should be enough for most networks with the size of 10-100 nodes. Press Update from the Remote operations frame (not the Local operations) and check the main window to see the update status messages.
To update the sink after the reboot time has elapsed stop the stack again with Tools->Stack stop and select Tools -> OTAP operations and press Update from the Local operations frame this time. Select Tools->Stack stop again and then Tools->Stack start to bring the sink back online. Now the network should be running the new software.
Additional Tips
The scratchpad deployment time depends on the size of the network under each sink. Very small networks take about 5 minutes and larger ones may take up to 30 minutes to distribute the new scratchpad to all devices.
The reboot time should be dependent on the size of the network. Use a longer reboot time for larger networks.
If an application needs to be removed through OTAP, it is done by sending an “empty” application image to the network.
{width=”0.3055555555555556in” height=”0.3055555555555556in”}
Wirepas Mesh has an OTAP failsafe mechanism which activates in the following situation:
There is a valid, new, unprocessed scratchpad stored in memory, and
- Remote update request has not been issued yet, i.e. the update delay
countdown is not running, and
- The device loses its connection to the network (no route to sink) and no connection can be re-established within one hour
After having no route to sink for one hour, Wirepas Mesh stack firmware will automatically mark the scratchpad for processing and reboots the device.
This failsafe mechanism is to make sure that the device will process the new scratchpad, even if it leaves the network for an extended period of time, before it can receive the remote update request. The expectation is, that while the node was away from the network, the rest of the network updated to a new stack firmware version. In rare cases, old and new firmware versions might not be able to communicate with each other. This failsafe mechanism makes sure that the stack firmware is updated even in such cases.
References
[1] WP-RM-108 – OTAP Reference Manual
[2] WP-RM-109 – OTAP Migration Appendix
[3] WP-RM-100 – Wirepas Mesh Dual-MCU API
[4] WP-RM-104 – Wirepas Mesh Diagnostics Reference Manual
